FLIGHT DESIGN CT2K - KA4020500-02 - Wheel, Main, Tundra

Chapter 4: Landing Gear
124
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4020503
C9997205W
C9997205I
KA4020502
C9996334
Part
Number
Description
Q-ty per
ASSY
Unit
C9997206M Daisy barke disk 4mm hole 10mm 1 pcs
KA4020502 Distance bushing 1 pcs
KA4020503 Bolt 1 pcs
KA4020505 Hub 1 pcs
KA4020510 Main wheel axis 1 pcs
C9996058 Bolt DIN 912 M6x25-8.8 6 pcs
C9996284B Bolt DIN 933 M6x20-8.8 3 pcs
C9996334 Self-locking nut DIN 985-M6, regular 9 pcs
C9996504 Washer DIN 125 A2B-6.4mm 9 pcs
C9996509 Spring washer DIN7980 M6 mm VZ 4 pcs
C9997030B Bearing 6004-2Z 2 pcs
C9997207F Tire 4-ply 6,00-6” Air TRAC (420x140) 1 pcs
C9997207J TUBE 15x6.00-6’’ VALVE TR87 1 pcs
C9997205I Pin for brake disk 4 pcs
C9997205U Caliper 1 pcs
C9997205V Half rim 6” 7020 upper with disc support 1 pcs
C9997205W Half rim 6” 7020 lower with disc support 1 pcs
C9997205Y Washer to Brake disk 1 pcs
C9997702C Compression spring 1x8x28.5x8.5 2 pcs
C9997214D Brake linings for magnesium caliper 2 pcs
C9996504
KA4020510
C9996284B
C9997205U
C9996509
C9997205Y
C9996058
C9997214D
C9997207J
C9997207F
C9997030B
C9997206M
KA4020505
KA4020500-02 - WHEEL, MAIN, TUNDRA
C9997205V
C9997702C
