FLIGHT DESIGN CT2K - KA4020001 Main Spring Bar

Chapter 4: Landing Gear
116
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4020001 MAIN SPRING BAR
Part Number Description
Q-ty
per
ASSY
Unit
KA4020001 Main spring bar 2 pcs
KA1000410L Rear reinforcement, left 1 pcs
KA1000410R Rear reinforcement, right 1 pcs
C9996083 Bolt DIN 912 M8x60-8.8 2 pcs
C9996260 Bolt DIN 931 M8x130-8.8 2 pcs
C9996336 Self-locking nut DIN 985-M8, regular 4 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 2 pcs
C9996567 Washer DIN 9021-8.4mm VZ 4 pcs
C9996060 Bolt DIN 912 M6x35-8.8 8 pcs
C9996334 Self-locking nut DIN 985-M6, regular 8 pcs
C9996565 Washer DIN 9021-6.4mm VZ 16 pcs
C9996083
KA1000410L
KA1000410R
C9996260
C9996567
C9996565
C9996334
C9996336
C9996060
KA4020001
KA4020001
C9996336
C9996505
