Chapter 7: Systems
344
Release 5. Issue 21.January.2008Copyright © 2008 Flight Design GmbH. All Rights reserved
C9997180A
C9996283A
C9996563
C9993369
Part
Number
Description
Q-ty per
ASSY
Unit
KB7050210 Bracket, Battery 1 pcs
C9996333 Self-locking nut DIN 985-M5, regular 4 pcs
C9996563 Washer DIN 9021-5.3mm VZ 8 pcs
C9997180A Battery Powersafe SBS 8 1 pcs
C9996283A Bolt DIN 933 M5x12-8.8 4 pcs
C9993369 Electrical wire AWG08 0,5 m
C9996333 KB7050210
KB7050200 - BATTERY INSTALLATION
