Chapter 6: Flight Control
273
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA6060000-01 - Trim Tab Control
Part Number Derscription
Q-ty per
ASSY
Unit
KA6060003 Rod 1 pcs
KA6060004 Bush 1 pcs
KA6060007-01 Spring 1 pcs
KA6060009 Rod 1 pcs
KA6060010 Rod 2 pcs
KA6060013 Bolt M5x17 2
pcs
KA6060020 Bolt 1 pcs
KA6060040 Telescopic Guide 1 pcs
KA6060100 Rocker 1 pcs
C9996208K Bolt DIN 7991 M5x25-8.8 1 pcs
C9996333 Self-locking nut DIN 985-M5, regular 11 pcs
C9996334 Self-locking nut DIN 985-M6, regular 1 pcs
С9996349 Hexagon nut DIN 934-M5-8 2
pcs
C9996503 Washer DIN 125 A2-5.3mm 3 pcs
C9997006C Rod end bearing, ext. thread GA5 4 pcs
C9997010 Angle joint M 5 2 pcs
C9997051
Nicopress oval sleeve 1.5-1.7 mm
for 1.6mm cable
2 pcs
C9997060 Thimble 2 mm 2 pcs
C9997065D Steel rope 7x7 1.6 mm 9.4 m
