Chapter 5: Power Plant
126
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Engine
Part
Number
Description
Q-ty per
ASSY
Unit
KA5000001 Bolt M10x125 1 pcs
KA5000002 Bolt M10x135 1 pcs
KA5000003 Bolt M10x139 1 pcs
KA5000005 Spacer 76 1 pcs
KA5000006 Spacer 87 1 pcs
KA5000007 Spacer 84 1 pcs
KA5000008 Spacer 94 1 pcs
KA5000009 Washer 6 pcs
KB5010100 Engine mount 1 pcs
C9996083 Bolt DIN 912 M8x60-8.8 6 pcs
C9996095 Bolt DIN 912 M10x50-8.8 3 pcs
C9996098F Bolt DIN 912 M10x120-8.8 1 pcs
C9996098J Bolt DIN 912 M10x150-8.8 1 pcs
C9996336 Self-locking nut DIN 985-M8, regular 6 pcs
C9996337 Self-locking nut DIN 985-M10, regular 4 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 6 pcs
C9996506 Washer DIN 125 A-10.5mm VZ 4 pcs
C9996511
Spring washer DIN7980 M10 mm VZ 4 pcs
C9996567 Washer DIN 9021-8.4mm VZ 6 pcs
C9996572 Washer DIN 9021-12mm VZ 4 pcs
C9997739 Silent block FIAT 38x14x10 mm 16 pcs
KA5010200 Engine frame, Small 1 pcs
