FLIGHT DESIGN CT2K - Page 130

Chapter 5: Power Plant
130
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
C9996289I Bolt DIN 931 M10x140-8.8 2 pcs
C9996289H Bolt DIN 931 M10x130-8.8 1 pcs
C9996289J Bolt DIN 931 M10x150-8.8 1 pcs
KA5000005 Spacer 76 1 pcs
KA5000006 Spacer 87 1 pcs
KA5000007 Spacer 84 1 pcs
KA5000008 Spacer 94 1 pcs
C9996098J Bolt DIN 912 M10x150-8.8 1 pcs
C9996337 Self-locking nut DIN 985-M10, regular 4 pcs
C9996506 Washer DIN 125 A-10.5mm VZ 4 pcs
C9996572 Washer DIN 9021-12mm VZ 4 pcs
C9997739 Silent block FIAT 38x14x10 mm 16 pcs
BIG & SMALL ENGINE MOUNT_2
C9996337
C9996506
C9996572
C9997739
KA5000007
C9996289J
KA5000006
KA5000008
C9996289I
C9996289H
C9996289I
KA5000005
