Chapter 6: Flight Control
188
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part Number Description
Q-ty per
ASSY
Unit
KA6010151-01 Main Plate 1 pcs
KA6010110
Choke 1 pcs
KA6010130 Trottle 1 pcs
KA6010142 Plate 1 pcs
KA6010153-01 Support 1 pcs
KA6010156-01 Fixation Plate 1 pcs
KA6010101-01 Body 1 pcs
KA6010152-01 Fixation Angle 1 pcs
KA6010157-01 Angle 1 pcs
KA6010107-01 Bolt M8x28 1 pcs
KA6010129 Pointer, Trim Tab Position 1 pcs
KA6010108-01 Bolt M8x60 1 pcs
KA6010123-01 Steering Wheel 1 pcs
C9996164A Bolt DIN 912 M4x12-8.8 4 pcs
C9996039 Bolt DIN 912 M5x30-8.8 2 pcs
C9996026 Bolt DIN 912 M4x20-8.8 2 pcs
C9996502 Washer DIN 125 A2-4.3mm 4 pcs
C9996503 Washer DIN 125 A2-5.3mm 4 pcs
C9996504 Washer DIN 125 A2B-6.4mm 1 pcs
C9996505 Washer DIN 125 A-8.4mm VZ 4 pcs
C9996565 Washer DIN 9021-6.4mm VZ 2 pcs
C9996332 Self-locking nut DIN 985-M4, regular 6 pcs
C9996333 Self-locking nut DIN 985-M5, regular 2 pcs
C9996334 Self-locking nut DIN 985-M6, regular 1 pcs
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996364 Cap for nut M6 1 pcs
C9996834 Countersunk rivet nut, steel, M5 2 pcs
C9996602 Stainl. steel rivet A2 3.2x8 1 pcs
C9997703B Spring 0,5x5,0x25,0 1 pcs
C9997051 Nicopress oval sleeve 1.5-1.7 mm 3 pcs
C9997056E Nicopress stop sleeve 1.5-1.7 mm 1 pcs
C9997816B Cable stop 621.1-Z15.2 zk 1 pcs
C9996562A Washer DIN 9021-4.3 mm A4 8 pcs
C9996029 Bolt DIN 912 M4x35-8.8 2 pcs
C9997065B Steel rope 7x7 1 mm 0,5 m
