Chapter 6: Flight Control
195
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA6020000_1 - Aileron Cotrol
Part Number Description
Q-ty per
ASSY
Unit
KA6020003 Bush 12 pcs
KA6020005 Bush 4 pcs
KA6020010L Push-pull rod, left 1 pcs
KA6020010R Push-pull rod, right 1 pcs
KA6020030L Rod 12x1.5 in the wing 1 pcs
KA6020030R Rod 12x1.5 in the wing 1 pcs
KA6020040L Rocker 1 pcs
KA6020040R Rocker 1 pcs
KA6020044 Angle 4 pcs
KA6020008 Bush 4 pcs
KA6020050L Aileron control rod rib box , left 1 pcs
KA6020050R Aileron control rod rib box 1 pcs
KA6020060 Cable 2 pcs
KA6020130 Rear fork rod support 1
pcs
KA6020200 Fork rod 1 pcs
KA6020210 H-Bracket 1 pcs
KA6020300L Rod rocker 1 pcs
KA6020300R Rod rocker 1 pcs
KA6020320L Side bracket 1 pcs
KA6020320R Side bracket 1 pcs
KA6020321 Pin 2 pcs
KA6020400 Rod 2 pcs
KA6020500 Rod 12x1.5 under pyramid 2 pcs
KA6040103 Stopper 2 pcs
KA6050001 Bush 8 pcs
KA3010203 Bush 4 pcs
C9996042 Bolt DIN 912 M5x45-8.8 2 pcs
С9996059 Bolt DIN 912 M6x30-8.8 2 pcs
С9996060 Bolt DIN 912 M6x35-8.8 12 pcs
С9996061 Bolt DIN 912 M6x40-8.8 6 pcs
С9996062 Bolt DIN 912 M6x45-8.8 2 pcs
С9996063 Bolt DIN 912 M6x50-8.8 2 pcs
С9996064 Bolt DIN 912 M6x60-8.8 2 pcs
С9996207 Bolt DIN 7991 M5x16-8.8 2 pcs
С9996208 Bolt DIN 7991 M5x20-8.8 8 pcs
С9996259A Bolt DIN 931 M6x30-8.8 3 pcs
С9996259S Bolt DIN 931 M8x55-8.8 2 pcs
С9996283 Bolt DIN 933 M5x16-8.8 2 pcs
С9996284 Bolt DIN 933 M6x16-8.8 3 pcs
С9996284B Bolt DIN 933 M6x20-8.8 1 pcs
С9996288 Bolt DIN 912 M6x70, A2 1 pcs
С9996333 Self-locking nut DIN 985-M5, regular 6 pcs
С9996334 Self-locking nut DIN 985-M6, regular 35 pcs
С9996503 Washer DIN 125 A2-5.3mm 6 pcs
С9996504 Washer DIN 125 A2B-6.4mm 34 pcs
С9996563 Washer DIN 9021-5.3mm VZ 2 pcs
С9996565 Washer DIN 9021-6.4mm VZ 8 pcs
