FLIGHT DESIGN CT2K - Page 222

Chapter 6: Flight Control
222
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
Part
Number
Description
Q-ty per
ASSY
Unit
KA6062100 Control Unit, Assembly 1 pcs
KA6062020 Rope, Aileron Trim Mechanism Control 1 pcs
KA6060004 Bush 1 pcs
С9996025 Bolt DIN 912 M4x16-8.8 2 pcs
C9996057 Bolt DIN 912 M6x20-8.8 1 pcs
C9996162 Screw ISO 7380 M5x16 4 pcs
C9996208 Bolt DIN 7991 M5x20-8.8 1 pcs
С9996502 Washer DIN 125 A2-4.3mm 4 pcs
C9996503 Washer DIN 125 A2-5.3mm 4 pcs
C9996504 Washer DIN 125 A2B-6.4mm 14 pcs
С9996332 Self-locking nut DIN 985-M4, regular 2 pcs
C9996333 Self-locking nut DIN 985-M5, regular 3 pcs
C9996334 Self-locking nut DIN 985-M6, regular 5 pcs
C9996162
C9996057
C9996504
C9996334
KA6062020
C9996208
C9996333
C9996503
KA6060004
С9996025
С9996502
С9996332
View A
