Chapter 6: Flight Control
237
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
T-bracket, Beam & Angles, Bracket & Small Angles
Part Number Description
Q-ty per
ASSY
Unit
KA6030301 Upper angle 1 pcs
KA6030302 Bracket 1 pcs
KA6030303L Small angle, left 1 pcs
KA6030303R Small angle, right 1 pcs
KA6030304L Main angle, left 1 pcs
KA6030304R Main angle, right 1 pcs
KA6030305 Bush 2 pcs
KA6030306 Angle 2 pcs
KA6030307 Bracket 1 pcs
KB6030320 Support 1 pcs
C9996025 Bolt DIN 912 M4x16-8.8 4 pcs
C9996035 Bolt DIN 912 M5x16-8.8 2 pcs
C9996039 Bolt DIN 912 M5x30-8.8 4 pcs
C9996060 Bolt DIN 912 M6x35-8.8 2 pcs
C9996283 Bolt DIN 933 M5x16-8.8 2 pcs
C9996283C Bolt DIN 933 M5x20-8.8 2 pcs
C9996333 Self-locking nut DIN 985-M5, regular 10 pcs
C9996334 Self-locking nut DIN 985-M6, regular 2 pcs
C9996503 Washer DIN 125 A2-5.3mm 10 pcs
C9996504 Washer DIN 125 A2B-6.4mm 2 pcs
C9997025 Bearing SKF 608-2RZ 1 pcs
