FLIGHT DESIGN CT2K - Page 246

Chapter 6: Flight Control
246
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KB6030400 - Commutation unit, German Version
Part
Number
Description
Q-ty per
ASSY
Unit
KA6030401 Guide bracket 2 pcs
KA6030402 Clamp 2 pcs
KA6030403 Stop angle 1 pcs
KA6030404 Tip 1 pcs
KA6030405 Tube 1 pcs
KA6030407 Stopper 2 pcs
KA6030409 Plate 1 pcs
KA6030410 Carrier in assembling 1 pcs
C9996022 Bolt DIN 912 M3x25-8.8 6 pcs
C9996025 Bolt DIN 912 M4x16-8.8 3 pcs
C9996029 Bolt DIN 912 M4x35-8.8 1 pcs
C9996285 Bolt DIN 912 M4x50, A2 4 pcs
C9996331 Self-locking nut DIN 985-M3, regular 6 pcs
C9996332 Self-locking nut DIN 985-M4, regular 8 pcs
C9996502 Washer DIN 125 A2-4.3mm 5 pcs
C9997198B Miniature switch 2 pcs
C9997788 Electric mechanism MT-10D 1 pcs
