FLIGHT DESIGN CT2K - Page 266

Chapter 6: Flight Control
266
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA6050000-01 - Rudder Control
Part
Number
Derscription
Q-ty per
ASSY
Unit
KA6050005 Sliding bearing upper 2 pcs
KA6050006 Sliding bearing lower 2 pcs
KA6050007 Covering plate lower 2 pcs
KA6050008 Covering plate upper 2 pcs
KA6050009 Rocker 2 pcs
KA6050011
Support 1 pcs
KA6050110
Pedal rear left 1 pcs
KB6050110
Pedal rear left 1 pcs
KA6050120 Pedal rear right 1 pcs
KB6050120 Pedal rear right 1 pcs
KA6050130 Pedal front left 1 pcs
KB6050130 Pedal front left 1 pcs
KA6050140 Pedal front right 1 pcs
KB6050140 Pedal front right 1 pcs
KA6050200 Rudder zero position device 1 pcs
KA6050213 Centering support 1 pcs
KA6050214 Centering support 1 pcs
C9993171A Shrinking hose RNF3000 12/4, transparent 0.2 m
C9996035 Bolt DIN 912 M5x16-8.8 2 pcs
C9996039 Bolt DIN 912 M5x30-8.8 2 pcs
C9996042 Bolt DIN 912 M5x45-8.8 2 pcs
C9996060 Bolt DIN 912 M6x35-8.8 2 pcs
C9996207 Bolt DIN 7991 M5x16-8.8 4 pcs
C9996208 Bolt DIN 7991 M5x20-8.8 4 pcs
C9996283C Bolt DIN 933 M5x20-8.8 6 pcs
C9996288 Bolt DIN 912 M6x70, A2 4 pcs
C9996333 Self-locking nut DIN 985-M5, regular 18 pcs
C9996334 Self-locking nut DIN 985-M6, regular 8 pcs
C9996503 Washer DIN 125 A2-5.3mm 10 pcs
C9996504 Washer DIN 125 A2B-6.4mm 2 pcs
C9996563 Washer DIN 9021-5.3mm VZ 20 pcs
C9996565 Washer DIN 9021-6.4mm VZ 16 pcs
C9997055 Nicopress oval sleeve 3.1-3.5 mm for 3.2mm cable 2 pcs
C9997062 Thimble 3 mm 4 pcs
C9997065N Steel rope 7x19 3.5 mm 10 m
C9997080 Turnbuckle Bluewave M6 2 pcs
C9997702W Compression Spring D-282B 1 pcs
