Chapter 6: Flight Control
271
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA6060000 - Trim Tab Control
Part
Number
Derscription
Q-ty per
ASSY
Unit
KA6060003 Rod 1 pcs
KA6060004 Bush 2 pcs
KA6060006 Washer 1 pcs
KA6060007 Spring 1 pcs
KA6060008 Washer 1 pcs
KA6060009 Rod 1 pcs
KA6060010 Rod 2 pcs
KA6060020 Bolt 1 pcs
KA6060100 Rocker 1 pcs
C9996039 Bolt DIN 912 M5x30-8.8 2 pcs
C9996208K Bolt DIN 7991 M5x25-8.8 1 pcs
C9996333 Self-locking nut DIN 985-M5, regular 13 pcs
C9996334 Self-locking nut DIN 985-M6, regular 1 pcs
С9996349 Hexagon nut DIN 934-M5-8 2
pcs
C9996503 Washer DIN 125 A2-5.3mm 1 pcs
C9997006C Rod end bearing, ext. thread GA5 4 pcs
C9997010 Angle joint M 5 2 pcs
C9997051
Nicopress oval sleeve 1.5-1.7 mm
for 1.6mm cable
2 pcs
C9997060 Thimble 2 mm 2 pcs
C9997065F Steel rope 1x19 1.5 mm 10 m
