FLIGHT DESIGN CT2K - Page 294

Chapter 7: Systems
294
Release 5. Issue 21.January.2008Copyright © 2008 Flight Design GmbH. All Rights reserved
KS7020000 - Fuel System, English Version
Part Number Description
Q-ty per
ASSY
Unit
KA7020002L Cap plate 1 pcs
KA7020002R Cap plate 1 pcs
KA7020003 Connection pipe 4 pcs
KA7020008 Gascolator adapter 1 pcs
KA7020009 Rubber seal ring 2 pcs
KA7020030L Fuel intake 1 pcs
KA7020030R Fuel intake 1 pcs
KA7020051 Refill cap 2 pcs
KA7020052 Refill cap flange 2 pcs
KA7020053 Rubber seal ring 2 pcs
KA7020060 Vent 2 pcs
KA7020071 Hot protection plate 1 pcs
KS7020100 Fuel valve drive 1 pcs
KS7020110
Fuel valve bracket 1 pcs
C9993183 Fuel line DIN 73379 E 5.5x11.5 black 0.77 m
C9993184A Fuel tube DIN 73379, 7.5x13.0 3.18 m
C9993189G Fire protection hose, red 2.8 m
C9993194H PU hose 1/2” OD x 3/8” ID 0.4 m
C9996022 Bolt DIN 912 M3x25-8.8 1 pcs
C9996025 Bolt DIN 912 M4x16-8.8 4 pcs
C9996040 Bolt DIN 912 M5x35-8.8 2 pcs
C9996207 Bolt DIN 7991 M5x16-8.8 8 pcs
C9996309 Nut M10x1 2 pcs
C9996331 Self-locking nut DIN 985-M3, regular 1 pcs
C9996332 Self-locking nut DIN 985-M4, regular 4 pcs
C9996333 Self-locking nut DIN 985-M5, regular 2 pcs
C9996334 Self-locking nut DIN 985-M6, regular 14 pcs
C9996337 Self-locking nut DIN 985-M10, regular 1 pcs
C9996503 Washer DIN 125 A2-5.3mm 2 pcs
C9996504 Washer DIN 125 A2B-6.4mm 12 pcs
C9996562 Washer DIN 9021-4.3 mm VZ 4 pcs
C9997257B Connector E-GET60-9-1/4-MS 2 pcs
C9997258G Connector F-Wek-1/4-MSv 2 pcs
C9997419F Fuel flow valve twin tank 1 pcs
C9997421 Gascolator 1 pcs
C9997715G Clamp 13 mm 6 pcs
C9997715H Clamp 14 mm 12 pcs
C9997730L O-Ring Material Viton 2 pcs
C9997731G Grommet 12 mm 2 pcs
C9997727C TY-wraps CV-100 white 10 pcs
