Chapter 4: Landing Gear
99
Copyright © 2008 Flight Design GmbH. All Rights reserved Release 5. Issue 21.January.2008
KA4010000 - Nose Landing Gear
Part Number Description
Q-ty per
ASSY
Unit
KA4010001 Rocker 1 pcs
KA4010002 Wheel axis 1 pcs
KA4010003 Nose wheel axis bush 2 pcs
KA4010004 Stopper 2 pcs
KA4010006 Bush 2 pcs
KA4010007 Distance bushing 1 pcs
KA4010008 Leather cap 2 pcs
KA4010010 Nose wheel fairing 1 pcs
KA4010100 Nose wheel rotation unit 1 pcs
KA4010200 Nose wheel 1 pcs
KA4010400L Rod, left 1 pcs
KA4010400R Rod, right 1 pcs
KA6020003 Bush 2 pcs
KA4010013 Packing 1 psc
KA4010014 Packing 1 psc
C9996057 Bolt DIN 912 M6x20-8.8 3 pcs
C9996059 Bolt DIN 912 M6x30-8.8 6 pcs
C9996064 Bolt DIN 912 M6x60-8.8 1 pcs
C9996161 Screw ISO 7380 M5x12 1 pcs
C9996218 Bolt DIN 7991 M6x30-8.8 2 pcs
C9996334 Self-locking nut DIN 985-M6, regular 10 pcs
C9996336 Self-locking nut DIN 985-M8, regular 2 pcs
C9996337 Self-locking nut DIN 985-M10, regular 2 pcs
C9996338 Self-locking nut DIN 985-M12, regular 1 pcs
C9996504 Washer DIN 125 A2B-6.4mm 1 pcs
C9996506 Washer DIN 125 A-10.5mm VZ 2 pcs
C9996507 Washer DIN 125 A-13 mm VZ 1 pcs
C9996509 Spring washer DIN7980 M6 mm VZ 2 pcs
C9996562 Washer DIN 9021-4.3 mm VZ 8 pcs
C9996563 Washer DIN 9021-5.3mm VZ 1 pcs
C9996565 Washer DIN 9021-6.4mm VZ 12 pcs
C9996763A Alu / steel rivet 4.8x10.0 Art.-Nr.915 904 864 8 pcs
C9997006B Rod end bearing, ext. thread GA8 4 pcs
C9997026K Bearing SKF 6002-2Z 2 pcs
C9997205A 4.00-4” UNION tire 1 pcs
C9997205G 4.00-4” tube with straight valve 1 pcs
C9997730F O-ring Simrit72, NBR 872, 28,0x5,0 2 pcs
