Printing Basics 143
Loading Print Media
Loading print media properly helps prevent jams and ensures trouble-free printing.
Before loading any print media, identify the recommended print side of the print media. This information is usually
indicated on the print media package.
Capacity
The standard 550 sheet tray and the optional 550 sheet feeder can hold:
• 550 sheets of the standard paper.
The bypass tray can hold:
• 150 sheets of the standard paper.
Print Media Dimensions
The maximum dimensions of print media that the standard 550 sheet tray and the optional 550 sheet feeder can
handle are:
• Width: 148 mm (5.83 inches) to 215.9 mm (8.5 inches)
• Length: 210 mm (8.27 inches) to 355.6 mm (14 inches)
The maximum dimensions of print media that the bypass tray can handle are:
• Width: 76.2 mm (3 inches) to 215.9 mm (8.5 inches)
• Length: 127 mm (5 inches) to 355.6 mm (14 inches)
