54 Basic Operation
Installing the Optional 550 Sheet Feeder and the Cabinet
IMPORTANT:
• If you install the optional 550 sheet feeder and the cabinet after setting up the printer, be sure to turn off the printer, unplug the
power cord, and disconnect all cables from the rear of the printer before installing the feeder and the cabinet.
1 Lock the two caster stoppers at the front of the cabinet.
2 Attach the four feet to the cabinet by inserting feet into the slots until they lock into position.
Make sure that all four feet are firmly inserted into the slots, and that they do not fall off. If these feet are not
inserted properly, they do not stay inserted firmly, or they do not lock into position.
3 Turn the dials of the four feet to the clockwise direction until the bottom of the feet have contact with the floor.
• Always lock the wheels of this product after installation. Otherwise, it may fall over or slide and cause injuries.
