Fuji Xerox DocuPrint CM405 df

Maintenance 439
Installing a Belt Unit
1 Unpack a new belt unit.
2 Remove the two orange packing materials first, and then the protective sheet from the belt unit.
3 Make sure that the arrow marks on the belt unit, and the printer face each other, and then insert the unit into the
printer until it clicks.
4 Close the top cover.
5 Lower the operator panel back in place.
