Fuji Xerox DocuPrint CM405 df User Manual

Basic Operation 45
 Rear View
 Duplex Automatic Document Feeder (DADF)
1 Control Board 7 Wall Jack Connector
2 Control Board Cover 8 Duplexer
3 Ethernet Port 9 2nd BTR
4 USB Port 10 Fusing Unit
5
Wireless Adapter Socket
11 Power Connector
6 Phone Connector 12 Rear Cover
1 DADF Cover 5 Document Feeder Tray
2 Document Guides 6 Document Stopper
3 DADF Glass 7 Front USB Port
4 Document Glass 8 DADF Feed Roller
1
2
3
4
5
6
7
8
9
10
11
12
1
8
2
4
5
7
3
6
