Copying 201
Edge Erase
To specify the top and bottom margins of the copy.
NOTE:
• Values marked by an asterisk (*) are the factory default menu settings.
1 Select the Output tab.
2 Select until Edge Erase appears, and then select Edge Erase.
3 Select or , or use the number pad to enter the desired value.
Top / Bottom 4 mm* (0.2 inch*) Specify the value in increments of 0.1 inch (1 mm).
0→50 mm (0.0→2.0")
Left / Right 4 mm* (0.2 inch*) Specify the value in increments of 0.1 inch (1 mm).
0→50 mm (0→2.0")
Middle 0 mm* (0 inch*) Specify the value in increments of 0.1 inch (1 mm).
0→50 mm (0→2.0")
To Next Page
