Maintenance 435
Replacing the Belt Unit, the 2nd BTR, and the Retard
Roller
You need to replace three parts (belt unit, 2nd BTR, and retard roller) at a time. Both the 2nd BTR and the retard
roller for replacement come with a new belt unit.
Fuji Xerox belt unit, 2nd BTR, and retard roller are available only through Fuji Xerox. To order by phone, see also
"Online Services" on page 475.
It is recommended that you use Fuji Xerox 2nd BTR, belt unit, and retard roller for your printer. Fuji Xerox does not
provide warranty coverage for problems caused by using accessories, parts, or components not supplied by Fuji
Xerox.
IMPORTANT:
• Ensure nothing touches or scratches the surface (black-colored film) of the belt unit. Scratches, dirt, or oil from your hands on
the film of the belt unit may reduce print quality.
This section includes:
• "Removing the Belt Unit" on page 436
• "Installing a Belt Unit" on page 439
• "Removing the 2nd BTR" on page 441
• "Installing a 2nd BTR" on page 441
• "Removing the Retard Roller Unit in the Standard 550 Sheet Tray" on page 442
• "Installing a Retard Roller in the Standard 550 Sheet Tray" on page 443
Overview
When a belt unit reaches its usable life-span, the following messages appear on the LCD panel.
Message Remaining Page Yield Printer Status and Action
Replace Transfer Unit
Soon.
5,000 pages The belt unit has become low. Prepare a new one.
Transfer Unit Life
Over
Open all covers.
Then, replace the
Transfer Unit.
Pressing [OK] will
reset the counter due
to the use of a new
Transfer Unit.
When the replacement
is done, press [OK].
- The belt unit has become empty. Replace the old belt
unit with a new one.
Select OK to reset the belt unit counter.
