Fuji Xerox DocuPrint CM405 df User Manual

96 Printer Connection and Software Installation
 Assigning an IP Address (for IPv4 Mode)
NOTE:
• When you assign an IP address manually in IPv6 mode, use the CentreWare Internet Services. To display the CentreWare
Internet Services, use the link local address. To check a link local address, see "Printing and Checking the System Settings
Page" on page 97.
• Assigning an IP address is considered as an advanced function and is normally done by a system administrator.
• Depending on the address class, the range of the IP address assigned may be different. On Class A, for example, an IP
address in the range from
0.0.0.0 to 127.255.255.255 will be assigned. For assignment of IP addresses, contact
your system administrator.
You can assign the IP address by using the operator panel.
1 Turn on the printer.
2 Ensure that Ready message appears on the LCD panel.
3 On the operator panel, press the (System) button.
4 Select Tools tab.
5 Select Admin Settings.
6 Select Network.
7 Select Ethernet.
8 Select TCP/IP.
9 Select Get IP Address.
10 Select Panel, and then select OK.
11 Ensure that the message This Settings Becomes Effective after Restart. appears, and then
select Close.
12 Select IP Address.
The cursor is located at the first octet of the IP address.
13 Enter the value of the IP address using the number pad.
14 Select .
The cursor moves to the next octet.
15 Repeat steps 13 to 14 to set all of the digits in the IP address, and then select OK.
16 Ensure that the message This Settings Becomes Effective after Restart. appears, and then
select Close.
17 Select Subnet Mask.
The cursor is located at the first octet of the subnet mask.
18 Enter the value of the subnet mask using the number pad.
19 Select .
The cursor moves to the next octet.
20 Repeat steps 18 to 19 to set the subnet mask, and then select OK.
21 Ensure that the message This Settings Becomes Effective after Restart. appears, and then
select Close.
22 Select Gateway Address.
The cursor is located at the first octet of the gateway address.

Fuji Xerox DocuPrint CM405 df Specifications

General

Brand	Fuji Xerox
Model	DocuPrint CM405 df
Category	All in One Printer
Language	English
