Basic Operation 47
12 (System) button
• Moves to the top level of the System menu.
13 (Job Status) button
• Moves to the top level of the Job Status menu.
NOTE:
• Moving to a different menu or returning to a previous screen cancels the current entry or setting. Make sure to save the
current entry or setting.
• For details on how to use the number pad to enter numbers, see "Using the Number Pad" on page 344.
Touch Panel - Top Service Menu Screen
This section describes the fields and buttons on the top service screen which is displayed by pressing the
(Services) button. This is the default screen that appears when the printer is turned on.
• Message Field
Displays the printer status, error message, and IP address assigned to the printer.
• Toner Status Icon
Displays the condition of toner in 6 levels. (The toner level for each color: 100%, 80%, 60%, 40%, 20%, 0%)
Selecting this icon moves to the Supplies tab.
• Wireless LAN Connection Status Icon
Displays the intensity of wireless signal when the wireless printer adapter is connected to the printer.
• Function Buttons
Allows you to set the features for functions such as Copy, E-mail, Scan To, Fax, Print from, and ID
Card Copy.
NOTE:
• If the Panel Lock setting for a function is set to Enable, the function is disabled and the menu for the function does not
appear on the screen. For details, see "Enabling the Panel Lock" on page 338.
• Copy
You can set the features for the Copy function.
See also:
• "Copying" on page 187
• E-mail
You can scan documents and send the scanned data as an e-mail attachment.
See also:
• "Sending an E-Mail With the Scanned Image" on page 238
Message Field
Function Buttons
Wireless LAN Connection
Status Icon
Toner Status Icon
To Next Page
