After replacing the front panel or Chassis ID EPROM
Check the SEL log files to verify whether a backup copy of the system board
settings has been transferred to the Chassis ID EPROM, see "Viewing and
clearing the System Event Log (SEL)" on page
117.
Chassis IDPROM: BMC FW backup successful
5.3.3 Updating expansion card firmware
For Japan:
Follow the instructions provided separately.
After replacing the expansion card, it is essential to upgrade the firmware to
the latest version without connecting any storage devices. The latest
expansion card firmware version is available from the Fujitsu support web
pages at:
https://ts.fujitsu.com/support/
For Japan:
https://www.fujitsu.com/jp/products/computing/servers/primergy/downloads/
Note on the boot watchdog
Before updating expansion card firmware, ensure that the boot
watchdog is disabled, see "Disabling the boot watchdog" on page 100
.
After updating expansion card firmware, enable the boot watchdog
again, see "Enabling the boot watchdog" on page 114.
Fujitsu does not assume responsibility for any damage done to the
server or for the loss of any data resulting from firmware updates.
Using the ServerView Update Manager
For more information on how to update the expansion card firmware using the
ServerV
iew Update Manager or Update Manager Express (UME), see the
following manuals:
ServerV
iew Update Manager: "ServerView Update Management" user guide
ServerView Update Manager Express: "Local System Update for
PRIMERGY Servers" user guide
Basic software procedures
106 Upgrade and Maintenance Manual TX1330 M4
