17.2.3.2 ID, CSS and Global Error indicators
Figure 337: ID, CSS and Global Error indicators
1 ID indicator, Global Error indicator,
CSS indicator
If CSS and Global Error indicators are located in the same place on the
I/O panel of the server, also check the indicators on the front panel to
determine if a CSS or Global Error event has been detected.
For more information on detected errors, see the System Event Log or
use the ServerView Operations Manager or iRMC web interface.
ID indicator (1)
See also
"iRMC-related status signals" on page 508.
Status Description
blue on The server has been highlighted using ServerV
iew
Operations Manager, iRMC web interface or the ID
button on the front panel for easy identification.
flashing blue
The server has been highlighted for easy
identification using the iRMC (AVR) with disabled
local VGA output.
Appendix A
TX1330 M4 Upgrade and Maintenance Manual 507
