14.7.2 Installing the Dual microSD 64GB Enterprise
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page
48.
▶
"Getting access to the component" on page 50.
▶
Remove the system fan module, see "Removing the system fan module" on
page 82.
Installing the Dual microSD 64GB Enterprise
Figure 291: Connecting the cable to the Dual microSD 64GB Enterprise
▶
Connect the cable to the Dual microSD 64GB Enterprise.
System board and components
TX1330 M4 Upgrade and Maintenance Manual 441
