12.8.3 Replacing the ultraslim ODD
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
–
Slotted screw driver (for bending in or out accessible drive
mounting brackets)
Preliminary steps
▶
"Locating the defective server" on page
45
.
▶
"Removing backup and optical disk media" on page 102.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
Removing the front cover is not required in order to replace the
ultraslim ODD.
Removing the defective ultraslim ODD
▶
Remove the ultraslim ODD adapter
, see "Removing an accessible drive" on
page
370.
▶
Remove the ultraslim ODD, see "Removing the ultraslim ODD from the
ultraslim ODD adapter" on page 399.
Installing the new ultraslim ODD
▶
Install the ultraslim ODD, see "Installing the ultraslim ODD into the ultraslim
ODD adapter" on page 396.
▶
Install the ultraslim ODD adapter, see "Installing an accessible drive" on
page 366.
Accessible drives
400 Upgrade and Maintenance Manual TX1330 M4
