Fujitsu PRIMERGY TX1330 M4

17 Appendix A
17.1 Mechanical overview
17.1.1
Server front
17.1.1.1 2.5-inch HDD/SSD model
The PRIMERGY TX1330 M4 server is available as a floorstand model and a
rack model.
The floorstand model can be converted to a rack model using an
optional conversion kit.
Figure 323: Server front 2.5-inch HDD/SSD model - example TX1330 M4 rack type
1 2.5-inch HDDs / SSDs
2 ODD
3 ID card
4 8x 2.5-inch HDD extension box / 8x
2.5-inch PCIe SSD extension box
5 Front panel module
TX1330 M4 Upgrade and Maintenance Manual 487
