For the cable plan, see "Appendix B" on page 519.
Concluding steps
▶
If applicable, "Installing the SAS expander board" on page 268
.
▶
"Installing the system fan in the air duct" on page 284.
▶
Insert all HDD/SSD modules, see "Installing 3.5-inch HDD modules" on
page 185.
Ensure that you reinstall the HDD/SSD module in the bay it was
located before the HDD backplane replacement.
▶
"Reassembling" on page
66
.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
7.5.6 Upgrading configuration from eight to 16 2.5-inch
HDDs/SSDs
Upgrade and Repair Unit
(URU)
Hardware: 20 minutes
Software: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
CAUTION
All data on all HDDs/SSDs in the array will be lost when deleting the
RAID array!
▶
Be sure to back up your data before deleting a RAID array.
▶
For more information, see the "ServerView Suite RAID
Management" user guide.
After installing or removing an additional backplane, never forget to
change the system information using the Chassis ID Prom Tool.
Hard disk drive (HDD) / solid state disk (SSD)
236 Upgrade and Maintenance Manual TX1330 M4
