12.6.3 Replacing the slimline ODD
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
–
Slotted screw driver (for bending in or out accessible drive
mounting brackets)
Preliminary steps
▶
"Locating the defective server" on page
45
.
▶
"Removing backup and optical disk media" on page 102.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
Removing the defective slimline ODD
▶
Remove the Multibay box, see "Removing the Multibay box" on page 378.
▶
Remove the slimline ODD from the Multibay box, see "Removing the
slimline ODD from the Multibay box" on page 380.
Installing the new slimline ODD
▶
Install the slimline ODD into the Multibay box, see "Installing the slimline
ODD into the Multibay box" on page 374.
▶
Install the Multibay box, see "Installing the Multibay box" on page 382.
Concluding steps
▶
"Reassembling" on page 66.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
Accessible drives
