Figure 203: Position of the shoulder screw caps
1 FBU 1 2 FBU 2
9.6.2 Installing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Shutting down the server" on page 47
.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
▶
Remove the system fan module, see "Removing the system fan module" on
page 82.
Expansion cards and backup units
TX1330 M4 Upgrade and Maintenance Manual 319
