Figure 69: Installing the cable clamp
▶
Push the cable clamp into the corresponding hole until it clicks in.
Concluding steps
▶
"Connecting the power cord" on page
79
.
▶
"Performing a fan test" on page 130.
6.4.2 Removing a hot-plug PSU
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
Note for removing a hot-plug PSU from a redundant configuration
If a hot-plug PSU should be removed from a redundant configuration, while the
system is in operation, proceed the following:
Power supply unit (PSU)
148 Upgrade and Maintenance Manual TX1330 M4
