While keeping the green locking latch pressed, pull the PSU out of its bay
(3).
CAUTION
Excessive temperatures could damage system components.
▶
Never leave the bay for the hot-plug PSU empty for more than
two minutes during operation.
Installing the dummy cover
Figure 74: Installing the dummy cover
▶
Insert the dummy cover into the empty bay with the impressed arrow symbol
facing to the left (see circle).
▶
Push the dummy cover into its bay until it locks in place.
CAUTION
▶
Always install dummy covers into unused bays to comply with
applicable EMC regulations and satisfy cooling requirements.
Concluding steps
No steps needed.
6.4.3
Replacing a hot-plug PSU
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Power supply unit (PSU)
152 Upgrade and Maintenance Manual TX1330 M4
