17.4 Minimum startup configuration
Field Replaceable Units
(FRU)
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Component Notes
System board no TPM, expansion cards or M.2 SSD installed
1 CPU with CPU heat
sink
installed in CPU 1
1 memory module installed in DIMM slot 1A
Front panel module
PSU Standard PSU or hot-plug PSU installed in bay
PSU 1
Table 6: Minimum startup configuration - components
Cable Notes
Front panel cable connected to the system board
Power cable
Table 7: Minimum startup configuration - cables
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page
48.
▶
Take the system down to its minimum startup configuration.
▶
"Connecting the power cord" on page 79.
▶
Connect a display to the server.
▶
Switch on the server, see "Switching on the server" on page 81.
Appendix A
516 Upgrade and Maintenance Manual TX1330 M4
