Fujitsu PRIMERGY TX1330 M4

Concluding steps
▶
If applicable, install the SAS expander board, see "Installing the SAS
expander board" on page 268.
▶
If applicable, install the expansion cards, see "Installing an expansion card"
on page 299.
▶
Install the system fan module, see
"Installing the system fan module" on
page 85.
▶
"Reassembling" on page 66.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
▶
"Resuming BitLocker functionality" on page 121.
14.4.4 Replacing the TPM
Field Replaceable Unit
(FRU)
Hardware: 40 minutes
Tools: Removing the system board:
–
Phillips PH2 / (+) No. 2 screw driver
Replacing the TPM:
– Bit screw driver
–
TPM bit insert
(*)
–
Thin slotted screw driver (2 x 0.4 mm)
(*)
–
Flat nose pliers
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
System board and components
TX1330 M4 Upgrade and Maintenance Manual 425
