Activity indicator (1)
Status Description
off The ODD is inactive.
green on The storage medium is being accessed.
17.2.2.4 Indicators on the hot-plug HDD/SSD module
Figure 335: Indicators on the hot-plug HDD/SSD module
1 Access indicator 2 Error indicator
Access Indicator (1)
Status Description
off The HDD/SSD is inactive.
green on The HDD/SSD being accessed.
Appendix A
504 Upgrade and Maintenance Manual TX1330 M4
