Insert the PCI adapter board in slot 1 (1).
▶
Fit the riser card onto the two spacer bolts (2).
▶
Fasten the riser card with the two screws (3).
▶
Connect the power cable (4).
▶
Install the expansion card in the riser card slot, see "Installing an expansion
card" on page 299.
Concluding steps
▶
If applicable, install the SAS expander board holder
, see "Installing the SAS
expander board holder " on page
271.
▶
Install the system fan module, see "Installing the system fan module" on
page 85.
▶
"Reassembling" on page 66.
▶
When working on a rack-mounted server: "Sliding the server into the rack"
on page 72.
▶
Connect all external cables to the expansion card installed in the riser card
slot.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
▶
"Resuming BitLocker functionality" on page 121.
9.5.5 Replacing a TFM
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Expansion cards and backup units
TX1330 M4 Upgrade and Maintenance Manual 313
