6 Power cable Backplane 2: X17 X3
For the cable plan, see "Appendix B" on page 519.
Installing the SAS expander board holder
Figure 166: Installing the SAS expander board holder (A)
▶
Take note of the two recesses (see circles).
Hard disk drive (HDD) / solid state disk (SSD)
TX1330 M4 Upgrade and Maintenance Manual 271
