Removing the defective 3.5-inch HDD module
▶
Remove the HDD module, see "Removing a 3.5-inch HDD module" on
page 189.
▶
If applicable, remove the HDD from the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 175.
Installing the new 3.5-inch HDD module
▶
If applicable, install the HDD in the installation frame, see "Handling HDDs
or SSDs without installation frame" on page
175.
▶
Install the HDD module, see "Installing a 3.5-inch HDD module" on
page 187.
Concluding steps
▶
If applicable, "Reassembling" on page 66.
▶
If the HDD is configured using a RAID controller with a RAID level higher
than "0", the rebuild will start automatically, see "Performing a RAID array
rebuild" on page 122.
7.4.6 Replacing a 3.5-inch HDD backplane
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 45
.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
▶
If applicable, "Removing the accessible drive bay cover" on page 61.
Hard disk drive (HDD) / solid state disk (SSD)
192 Upgrade and Maintenance Manual TX1330 M4
