Concluding steps
▶
If applicable, install the SAS expander board holder, see "Installing the SAS
expander board holder " on page
271.
▶
If applicable, remove break-outs from the system fan module (see
Figure 170 or Figure 171).
▶
Install the system fan module, see "Installing the system fan module" on
page 85.
▶
"Reassembling" on page 66
▶
Connect all external cables.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
▶
"Updating expansion card firmware" on page 106.
▶
"Enabling Option ROM scan" on page 107.
▶
"Resuming BitLocker functionality" on page 121.
▶
If applicable,"Configuring LAN teaming" on page 128.
9.5.2 Removing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Suspending BitLocker functionality" on page 99
.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
Remove all external cables from the expansion card to be removed.
▶
"Getting access to the component" on page 50.
Expansion cards and backup units
TX1330 M4 Upgrade and Maintenance Manual 305
