Standard system fan module
Figure 170: Standard system fan module
1 Air duct
2 System fan 1, 120 x 38 mm
3
Breakouts
CAUTION
▶
Since the system fan is not redundant, it has to be replaced
immediately in case of defects or prefailure events.
Fans
278 Upgrade and Maintenance Manual TX1330 M4
