iRMC microSD card
The iRMC microSD card is necessary for using the embedded Lifecycle
Management (eLCM) functionality of the iRMC.
●
M.2 SSD
The system board of
fers two M.2 slots (Key M) with support for 42 mm,
60 mm, 80 mm and 1
10 mm long M.2 SSDs. With the M.2 SSD an internal
SSD is offered. This SSD can be configured as a boot device or data
storage device.
●
Dual microSD 64GB Enterprise
The system board is optionally equipped with a Dual microSD 64GB
Enterprise. The Dual microSD 64GB Enterprise offers an Integrated
Hardware RAID solution based on RAID-on-Chip (ROC) technology.
14.3 CMOS battery
14.3.1 Replacing the CMOS battery
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less; recommended: tooth pick
CAUTION
▶
The CMOS battery must be replaced with an identical battery or
with a battery type recommended by the manufacturer.
▶
Keep lithium batteries away from children.
▶
Do not throw batteries into the trash can. Lithium batteries must be
disposed of in accordance with local regulations concerning special
waste.
▶
For more safety information, see "Environmental protection" in the
operating manual of your server.
▶
Ensure to insert the CMOS battery with the positive pole facing
up!
System board and components
414 Upgrade and Maintenance Manual TX1330 M4
