Figure 285: Slots and bolts for M.2 SSDs
1 M.2 slot 1 2 M.2 slot 2
14.6.2 Installing an M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
–
Hexagon screw driver
Preliminary steps
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page
48.
▶
"Getting access to the component" on page 50.
System board and components
TX1330 M4 Upgrade and Maintenance Manual 433
