Figure 24: Installing the top cover (B)
▶
Close the locking lever on the top cover (1). This will slide the top cover shut
engaging the locking mechanism (2).
4.5.2.3
Installing the server in the rack
CAUTION
At least two people are needed to position the server on the rack rails.
(For Japan, see "安全上のご注意".)
Basic hardware procedures
TX1330 M4 Upgrade and Maintenance Manual 69
