14.6.4 Replacing an M.2 SSD
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 45
.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
▶
Remove the system fan module, see "Removing the system fan module" on
page 82.
▶
If applicable, remove the SAS expander board holder without disconnecting
cables, see "Removing the SAS expander board holder" on page 273.
Position the SAS expander board holder on the HDD cages to get more
space.
▶
If applicable, remove an expansion card, see "Removing an expansion
card" on page 305.
Replacing the M.2 SSD
▶
Remove the defective M.2 SSD, see "Removing the M.2 SSD" on page 437.
▶
Install the new M.2 SSD, see "Installing the M.2 SSD" on page 434.
Concluding steps
▶
If applicable, install an expansion card, see "Installing an expansion card"
on page 299.
▶
If applicable, install the SAS expander board holder, see "Installing the SAS
expander board holder " on page 271.
