12.4 Removing accessible drives
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 45
.
▶
"Removing backup and optical disk media" on page 102.
▶
"Verifying and configuring the backup software solution" on page 102.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
The front cover only needs to be removed in order to remove accessible
drive dummy covers.
Removing an accessible drive
▶
Remove all cables from the accessible drive.
▶
Open the locking bar, see "Opening the accessible drive locking bar" on
page 89.
Accessible drives
370 Upgrade and Maintenance Manual TX1330 M4
