7.4 3.5-inch HDD configurations
7.4.1 Equipping the 3.5-inch HDD bays
The HDD bays can be equipped with 3.5-inch HDD modules or 2.5-inch
HDD/SSD modules, see "2.5-inch HDD/SSD and 3.5-inch installation frame"
on page
177.
7.4.2 Overview of configurations
7.4.2.1 Configuration with up to four HDD modules
Figure 97: Configuration with up to four 3.5-inch HDDs
The HDD numbering as listed in the ServerView RAID Manager differs
from the HDD mounting order:
Hard disk drive (HDD) / solid state disk (SSD)
TX1330 M4 Upgrade and Maintenance Manual 181
