Remove the top cover
.
4.4.2.4
Removing the rack front cover
You remove the rack front cover when installing/removing accessible
drives or HDD extension boxes.
Figure 8: Removing the ID card (rack model)
▶
Remove the ID card from the server.
It may be necessary to pull out on the ID card rather firmly. However,
do not apply excessive force.
Basic hardware procedures
TX1330 M4 Upgrade and Maintenance Manual 55
