7.6.4 Installing the 4x 3.5-inch HDD extension box
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 10 minutes
Tools:
Slotted screw driver (for bending in or out accessible drive
mounting brackets)
After installing or removing an extension box, never forget to change the
system information using the Chassis ID Prom Tool.
Preliminary steps
▶
"Suspending BitLocker functionality" on page 99
.
▶
"Shutting down the server" on page 47.
▶
"Disconnecting the power cord" on page 48.
▶
"Getting access to the component" on page 50.
Removing accessible drive dummy covers
▶
Remove accessible drive filler covers from the required bays, see
"Accessible drive filler covers" on page 92.
▶
Remove accessible drive covers, see "Accessible drive covers" on page 95.
Installing the ultraslim ODD into the HDD extension box
▶
If applicable, install the ultraslim ODD into the new 4x 3.5-inch HDD
extension box, see "Installing the ultraslim ODD" on page 384.
Installing the HDD backplane
▶
If applicable, install the HDD backplane on the 4x 3.5-inch HDD extension
box, see "Installing the new HDD/SSD backplane" on page 253.
Hard disk drive (HDD) / solid state disk (SSD)
256 Upgrade and Maintenance Manual TX1330 M4
