Installing HDDs/SSDs modules into the 8x 2.5-inch HDD/SSD extension
box
▶
Install HDD modules or HDD dummy modules into the additional HDD bays,
see "Installing a 2.5-inch HDD/SSD module" on page 215 and
"Installing a
2.5-inch dummy module" on page 218.
For detailed information on HDD mounting order, see "2.5-inch HDD/
SSD configurations" on page 209.
Concluding steps
▶
If applicable, convert your standard power supply to a redundant power
supply, see
"Converting a standard power supply to a redundant power
supply" on page 164.
▶
"Reassembling" on page 66.
▶
"Connecting the power cord" on page 79.
▶
"Switching on the server" on page 81.
▶
Update the system information of your server using the Chassis ID Prom
Tool, see "Using the Chassis ID Prom Tool" on page 126. Select the
corresponding system name.
▶
"Resuming BitLocker functionality" on page 121.
7.6.2 Removing the 8x 2.5-inch HDD/SSD extension
box
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 10 minutes
Tools: tool-less
After installing or removing an extension box, never forget to change the
system information using the Chassis ID Prom Tool.
Hard disk drive (HDD) / solid state disk (SSD)
TX1330 M4 Upgrade and Maintenance Manual 247
